Technical data
Moreless| Pincount | 24 |
| Material contact | Copper alloy |
| Plating contact | Selective Au |
| Material insulator | Thermoplast UL94V-0 |
| Rated current IEC | 5,0 A |
| Withstand voltage | 100 V RMS for 1 Minute |
| Operating temperature | -40°C to +85°C |
| Max. processing temper. | 260°C for 10 seconds |
| Industry standard | USB 4 Gen 3 |
| Unmated force | 8-20 N |
| Durability | 10.000 Zyklen |
| Insulation resistance | 100 MOhm min |
| Packaging | Reel |
