Technical data
Moreless| Pitch (mm) | 3,50 |
| Material contact | Copper alloy |
| Plating contact | Sn |
| Material insulator | PA 6.6, UL94V-0 |
| Rated current IEC | 12,0 A |
| Rated voltage | 300 V AC |
| Withstand voltage | 2500 V AC for 1 Minute |
| Operating temperature | -40°C to +105°C |
| Orientation to PCB |
Parallel
|
| Connection type | screw clamp |
| AWG | 12-30 |
| Approvals |  |
| Packaging | Roll packaging on request |
