Technical data
Moreless| Pitch (mm) | 0,80 |
| Pincount | 60, 80, 100 |
| Material contact | Phosphor bronze |
| Material insulator | High temp. thermoplast UL94V-0 |
| Rated current IEC | 0,5 A |
| Withstand voltage | 250 VAC for 1 minute |
| Operating temperature | -40°C to +105°C |
| Max. processing temper. | 260°C for 10 seconds |
| Board termination |
SMD Gull Wing
|
| Orientation to PCB |
Vertical
|
| Plating clip | Au |
| Cap | With kapton tape |
| Packaging | Reel |
